Panasonic HTB600 Soundbar sc-htb600egk

Amp Type 2.1 ch

Total RMS Stereo Mode Power 360W

Front Speaker (Left / Right) 80W + 80W (X kHz, THD X%, XO, X kHz LPF)

Subwoofer 200W (X Hz, THD X%, XO, X kHz LPF)

Speaker Unit Woofer 4.5 cm x 2 / ch, Cone type

Bass Expand Bass Reflex Port

Speaker Unit 16 cm x 1, Cone type

Bass Expand Bass Reflex Port

Wireless Yes

Bluetooth Version Bluetooth® Ver 4.2

Codec SBC

Connectivity Multi-Pairing (MAX 8 Devices)

Support Format WAV

Music Streaming App *¹Yes (Bluetooth)

HDMI Input x 1

Output x 1 (eARC)

Audio Input Optical Input x 1

USB Port x 1 (For Service Use and Customer Software Update)

Sound Function Surround 3D Surround / Virtual Surround

SOUND MODE STANDARD, MUSIC, CINEMA, VOICE, NEWS

Bass Boost Yes

Subwoofer Level Adjustment Yes(5 levels)

Clear-mode Dialog Yes

Decoder Function / Format LPCM

Dolby Digital Yes

Dolby Digital + Yes

Dolby True HD Yes

Dolby Atmos Yes

DTS Digital Surround Yes

DTS ES Yes

DTS 96/24 Yes

DTS-HD HR Yes

DTS-HD High Resolution Audio Yes

DTS X Yes

DTS Virtual X Yes

HDMI CEC Yes

Audio Return Channel(for HDMI Output)*³ Yes(eARC)

1080p, Deep Color, x.v. Color Yes

4K Pass through Yes

FULL HD 3D COMPATIBLE Yes

HDR10 Pass Through Yes

Dolby Vision Pass Through Yes

USB Function Service Use Yes

Customer Software Update Yes

Wall Mountable Yes

Matching TV Size 43 inch and above

Main Unit Power Supply AC 220 - 240 V, 50 Hz

Dimmer Bright/Dark/Display Off

Auto OFF Yes

Main Unit (W x H x D) For table top layout 962 x 56 x 120 mm

Subwoofer (W x H x D) 191 x 412.5 x 385 mm

Color Black

Remote Control Yes

AC Cord Yes

Wall Mount Bracket Yes

Operating Instruction Yes

Note

*1 Available for iOS and Android. Download on the App Store. Download on Google Play?.

*2 Enabled by software update.

*3 ARC Audio Return Channel compatible TV is required.

*4 Specifications are subject to change without notice. All numbers given here are approximate.TRADEMARK NOTICE Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. Google Play is a trademark of Google LLC. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners.

Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories.

For DTS patents, see http//patents.dts.com.

Manufactured under license from DTS, Inc.

DTS, the Symbol, DTS and the Symbol together, VirtualX, and the DTS VirtualX logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries.

© DTS, Inc. All Rights Reserved.
