Loewe klang multiroom forstærker klang-multiroom-forstaerker

Audio (acoustic)

Channel configuration (speaker layout) 2.0 (stereo)

2-channel crossover Y(var. level, var. frequency)

Audio (electric)

Frequency range (Hz) @ ±1 dB 20-20.000

Class-D amp Y (min. speaker impedance 4O)

Power (watts sine / music) 300 / 600 @ 8O, 600 / 1.200 @ 4O

Total harmonic distortion @ 1 watt /10 watts < 0,05 / < 0,05

Dynamic range / Signal to noise ratio (dB) 24 bit / > 100

Damping factor of power stage (dB) > 50

Scalable output power / limiter / custom tuning Y/Y/Y

Bass and treble control / loudness Y(remote) / -

Balance / gain adjustment (dB) Y/Y (subwoofer)

Mono mix function Y

Protection circuit heat / current / voltage / short cut Y/Y/Y/Y

Dolby Audio / Digital / Digital Plus / Volume / Atmos / Atmos Music via klang bar mr

DTS HD / DTSX via klang bar mr

Operation

Display technology White LED + Color LED (dimmable)

Screen resolution (pixels) LED line

Screen diagonal (cm / inch) 6,5 / 2,5

Smart apps (all Android + iOS) DTS Play-Fi, my Loewe app

Voice control by Alexa skills Y

Software update (via USB / Internet) Y/Y (DTS Play-Fi)

Media and receiption

USB music player Y

Bluetooth music player Y

Internet radio Y (via DTS Play-Fi app)

DTS Play-Fi / Hi-Res Audio Y/Y

Spotify Connect / Google Cast / Apple AirPlay Y/Y/Y

Roon tested Y

Multiroom audio support Y

Multichannel home cinema support Y (front / rear surround)

Connectivity and Interfaces

HDMI Y (PCM audio only)

HDCP 2.2 / HDMI-CEC / ARC / eARC - / Y / Y / -

USB 1 x USB 2.0 (MP3 only)

Bluetooth Y

WLAN (Wi-Fi) integrated Y

LAN network connection 2 x RJ45 (daisy chain)

Wireless Digital Audiolink (second generation) Y

AV receiver analog pre-amp cinch out 5.1 / 3.1 / 2.1 / 2.0 - / - / Y / Y (gold plated)

Analogue audio cinch in / out (stereo) Y / Y (gold plated)

Speaker terminals / banana plugs (stereo) Y / Y (gold plated)

Wall mount Y (integrated)

Network and formats

WLAN (Wi-Fi) standard IEEE 802.11a/b/g/n/ac

WLAN (Wi-Fi) power (max. mW) <100

WLAN (Wi-Fi) frequency range 2400-2483,5 / 5150-5725 MHz

WLAN (Wi-Fi) encryption WEP 64, 128 Bit (ASCII, HEX)

WLAN (Wi-Fi) encryption WPA WPA PSK, WPA2 AES, WPS

Bluetooth standard 5.0

Bluetooth power (max. mW) <10

Bluetooth frequency range 2,4 GHz

Bluetooth protocols A2DP SNK, AVRCP

Supported audio formats PCM, MP3, M4A, AAC, FLAC, WAC, AIFF, Hi-Res AUDIO

Supported video formats -

Energy and environment

Mains voltages AC 220-240V, 50/60 Hz

Power consumption eco standby mode (watts) 0.5

Power consumption network standby mode (watts) -

Power consumption multiroom sleep mode (watts) 5

Ambient temperature while in operation 5-40° C

Relative humidity (non-condensing) 20-90%

Dimensions

Mains voltages AC 2,2

Power consumption standby / network standby (watts) 21,7 x 7,9 x 21,7

Scope of Delivery

Remote control (incl. batteries) Loewe remote mr (2x CR2032)

Manual / power cord Y / Y

Others HDMI cable, Quick start guide
